Biomass pellet complete equipment is an important component of modern renewable energy industry. Liyang Rongda Machinery Co., Ltd. specializes in producing various types of biomass pellet machines and related supporting equipment, providing customers with complete solutions from raw material processing to finished product packaging.

Range of Biomass Raw Materials

Our equipment can process various biomass raw materials, including: wood chips, sawdust, shavings, corn stalks, wheat stalks, cotton stalks, caragana, branches, rice straw, rice husks, peanut shells, palm shells, furniture factory waste materials, old fabric strips, newspapers, corn cobs, branches, leaves, sawdust, etc. In addition, solid waste such as mushroom residue, furfural residue, and wine lees can also be used as raw materials for processing.

Through our equipment, these raw materials can be processed into biomass fuel pellets, or coarse fiber feed pellets, achieving efficient utilization of resources.

Our biomass pellet machines are mainly divided into two categories: flat die biomass pellet machines and ring die biomass pellet machines. These machines can take agricultural and forestry processing waste such as wood chips, straw, rice husks, bark, etc. as raw materials, and through pre-treatment and processing, solidify them into high-density fuel pellets. It is an efficient and clean renewable energy source.

Advantages of Biomass Fuel Pellets

Biomass molded fuel produced by biomass pellet machines has the following significant advantages:

• High calorific value, low ash content, environmentally friendly fuel
• Used for heating, household stoves, boilers, biomass power plants, etc.
• Using agricultural waste such as rice straw, wheat straw, corn stalks as raw materials
• Processed through equipment with crushing, compression and other processes to form solid biomass fuel that can be directly burned
• The compressed biomass pellet fuel has high density and small volume, convenient for storage and transportation
• Calorific value can reach 3200-4500 kcal, with characteristics of easy ignition, low ash content, and low cost
• Can replace firewood, raw coal and other fuels, applied to heating, household stoves, industrial boilers, biomass power plants, etc.

A complete pellet production line includes multiple stages. Taking wood chip pellets as an example, the main processes include: crushing stage—fine powder stage—drying stage—pelletizing stage—cooling stage—packaging stage—dust removal stage (the machines selected vary according to different requirements).

filter_none

Crushing Stage

Main machines include drum wood chipper, comprehensive crusher, disc tree stump crusher. The drum wood chipper is a special equipment for producing wood chips. The machine consists of body, knife roller, upper and lower feeding rollers, conveyor belt, hydraulic system and other parts. The knife roller is equipped with two, four, or six flying knives. According to the different thickness and diameter of the material to be cut, the upper feeding roller assembly can float up and down within a certain range with the help of the hydraulic system. The body is welded with high-strength steel plate, which is the supporting foundation of the entire machine, foundation-free, saving funds and convenient and flexible.

construction

Fine Powder Stage

Mainly includes multifunctional crusher, high-efficiency crusher. Pre-processing material requirements: wood chips no more than 2cm thick. Post-processing material range: wood chips less than 8mm. Working principle: material enters the hammer crusher from the feed inlet, collides violently with high-speed hammers, gets impacted into the acceleration zone, where particle velocity can be increased to near the end linear velocity of the hammers in a short time, and moves in a circular motion with the hammers. In the curved speed zone, a material ring flow layer is gradually formed while the material is further crushed, and the crushed material is discharged from the equipment outlet.

local_fire_department

Drying Stage

Mainly single drum dryer, vacuum dryer, triple drum dryer. According to the original moisture content of the material and the required discharge moisture content, calculate the evaporation required and select the drum diameter and hot air furnace model. This stage mainly dries wood chips and sawdust with moisture content of 20%-60% to 10-18%, then proceed to the next stage.

circle

Pelletizing Stage

Mainly vertical ring die pellet machine, producing pellet diameter range of 6-12mm. This stage is also the most core part of the entire production line.

ac_unit

Cooling Stage

Counterflow cooler. The pellets produced by the biomass pellet machine have a temperature of about 60 degrees Celsius and need to be cooled to room temperature before packaging.

inventory

Packaging Stage

The pressed pellets need to be packaged before being sold to customers. According to requirements, our company uses automatic packaging machines, which have large packaging capacity and fewer manual workers, greatly reducing packaging costs. Generally, bag packaging (20-50kg/bag) or ton bags are used.

1. Investment Analysis for Biomass Complete Equipment

Biomass complete equipment investment is substantial, and there are risks involved. This is not a project that can be started with just a few thousand or tens of thousands of yuan. The investment for machinery alone requires at least 200,000-300,000 yuan for a production capacity of 1-1.5 tons per hour, which is also a low requirement. Additional costs need to be considered such as factory space, labor, electricity, machine wear, and raw materials. For detailed cost calculations, you can contact us, and we can provide you with a comprehensive breakdown based on your situation, hoping to assist you.

2. Raw Material Issues for Complete Biomass Wood Chip Pellet Machine

Raw materials must be abundant and preferably supplied stably. The range of raw materials is quite broad, including various wood chips, sawdust, waste materials, corn stalks, etc. However, to make profits, it's better to choose wood chips. Stalks have low calorific value, generally around 3000-3500 kcal, making the pellets difficult to sell at premium prices. Small pellet machines can also produce 10 tons of pellets. Before entering this industry, thoroughly investigate the raw material supply.

3. Profit Margin Analysis

The profit margin for complete biomass wood chip pellet machines is thin. The profit margin for wood chip pellets mainly depends on high demand volume - larger quantities generate more profit. Therefore, large-scale production is key to improving profitability.
